Article: Andy Collinson Overview Most people will not have access to a electronics laboratory or be able to afford an oscilloscope, so here is an alternative. Winscope is a software application that will use your sound card to sample input waveforms and display results. The Oscilloscope allows you to study any signal in real time, measure frequencies, study realtime signal spectra and plot Lissajous patterns. In addition, winscope also has a storage facility and has a powerful FFT (fast fourier transform) routine, which enables winscope to act as a spectrum analyzer. Hana Hetalia Mmd Models. There are some drawbacks however with winscope, mainly: - non-calibrated amplitude level (difficult to use as digital multimeter) - relatively low bandwidth (20 Hz - 20 kHz) - possibility of damage of a PC when connecting to an unknown signal source. (See Warnings). Warning: OSCILLOSCOPE IS SUPPLIED TO YOU AS IS, AND IN NO CASE THE AUTHOR OF OSCILLOSCOPE IS RESPONSIBLE FOR PERSONAL INJURY, HARDWARE AND/OR DATA DAMAGE, PROPERTY DAMAGE OR PROFIT LOSS ARISING FROM USE OR INABILITY TO USE THE OSCILLOSCOPE.

The flexibility of integration of data acquisition software. A digital storage oscilloscope is an. Is presented as a Lissajous figure. Here is a list of best free Oscilloscope Software for Windows. These software work as CRO software on your PC to analyze signals and sound. If you are on low budget.

THE AUTHOR DOES NOT GUARANTEE THE FITNESS OF OSCILLOSCOPE FOR ANY PARTICULAR PURPOSE. OSCILLOSCOPE IS NOT INTENDED FOR INDUSTRIAL OR COMMERCIAL USE. IN GENERAL, USE OSCILLOSCOPE AT YOUR OWN RISK. ALWAYS CONSULT YOUR SOUND CARD MANUAL FOR DETAILS ON CONNECTING TO EXTERNAL DEVICES. General Information Winscope 2.51 is designed by Konstantin Zeldovich and he has graciously distributed it as freeware. It was wrote for windows 95 but works happily on windows XP and Windows Me. I have not tested it on Windows 7 or Windows Vista.

It does however work perfectly on linux, using wine. Specifications Dual trace digital storage oscilloscope with realtime spectrum analyzer and correlometer. Buffer length: 52 ms Bandwidth: 20 Hz - 20 kHz max Input level: about 2 VAC, limited by sound card capabilities Display refresh: ca. 6 fps Data export: disk file or Windows clipboard, text format Safety measures when using Oscilloscope Being software, Winoscope itself cannot damage your hardware, but it is very easy to burn out at least your sound card when trying to investigate some signal with unknown amplitude and DC offset.

So, you must always be extremely careful when establishing an electrical connection between your computer and external equipment. It may be a good practice to use first a conventional multimeter or oscilloscope to find out whether signal levels are acceptable for your sound card. It is safe to connect to any audio/video equipment using standard line-in jacks and cables.
